Corrugated sidewall conveyor belt is one of the most effective ways of elevating materials in a confined space.

The economy is achieved by single belt operation. Wide range materials can be handled,less space requirement, no transfer point , low maintenance and big capacity.

Corrugated sidewall belt can be designed into a set of complete transportation system according to application.

Cleat types:T,TS,C,TC and TCS

The cleat is made of enforced fabric,solid,anti-shock to avoid distortion.

"TS"and "TCS"cleats are normally used for abrasion condition. "T" and "TS" cleats are normally used

up to 40°, "TC" and "TCS" are normally used from 40° to 90°. Sidewall,cleat and base belt are joined

through hot vulcanization. Cleats and sidewalls are joined through bolt to prevent leakage of material.

Sidewall and Cleat detail parameter information as the below.
